Yeni
PULS CT5.241 POWER SUPPLY - DIN RAIL - RAY MONTAJLI GÜÇ KAYNAĞI
15.093,76 TL
Kategori
Stok Kodu
CT5.241
Fiyat
328,50 USD + KDV
1.649,68 TL den başlayan taksitlerle!
INPUT: 380/400/440V 50/60HZ
OUTPUT: 24-28VDC 120W 5A
Product Attributes
OUTPUT: 24-28VDC 120W 5A
Product Attributes
|
Type
|
Description
|
Select All
|
|---|---|---|
|
Category
|
|
|
|
Manufacturer
|
PULS, LP
|
|
|
Series
|
|
Part Status
|
Active
|
|
|
Input Type
|
AC
|
|
|
Number of Outputs
|
1
|
|
|
AC Voltage - Input
|
323 ~ 576 VAC (3 Phase)
|
|
|
Voltage - Output 1
|
24V
|
|
|
Voltage - Output 2
|
-
|
|
|
Voltage - Output 3
|
-
|
|
|
Voltage - Output 4
|
-
|
|
|
Voltage - Output 5
|
-
|
|
|
Voltage - Output 6
|
-
|
|
|
Current - Output (Max)
|
5A
|
|
|
Power (Watts)
|
120W
|
|
|
Voltage - Isolation
|
500 V
|
|
|
Applications
|
ITE (Commercial)
|
|
|
Efficiency
|
92.9%
|
|
|
Operating Temperature
|
0°C ~ 70°C (With Derating)
|
|
|
Features
|
Adjustable Output, Load Sharing
|
|
|
Size / Dimension
|
4.61" L x 2.44" W x 4.88" H (117.0mm x 62.0mm x 124.0mm)
|
|
|
Approval Agency
|
ABS, CSA, DNV GL, EAC, IEC, SEMI, UL
|
|
|
Standard Number
|
Class I Div 2; F47; 508; 60950-1; 61010-2-201
|
|
|
Minimum Load Required
|
-
|
|
|
Base Product Number
|
